AccurioPress C7090

AccurioPress C7090

    ​
  •  INTELLIGENT AUTOMATION - By instantly detecting the precise stock you’re using, the Intelligent Media Sensor IM-101 significantly reduces production time. With real-time quality and VDP inspection, the IQ-501 Intelligent Quality Care Unit also ensures perfectly consistent color reproduction and front-to-back registration
  • ENHANCED FINISHING - The in-line TU-510 4-edge trimming unit cuts, creases and perforates to produce stunning ready-to-box fullbleed book jackets, brochures, cards and more. Removing the need for off-line finishing means fewer operator touchpoints for faster and more efficient print runs.
  • FLAWLESS QUALITY - Our latest Simitri V toner is eco-friendly, energy efficient and formulated for performance. With a low fusing temperature, it reproduces superb color quality. Combined with an output resolution of 3600 equivalent x 2400 dpi you can deliver outstanding results even during the fastest, longest print runs.
  • ADVANCED CAPABILITIES - With auto-duplex long sheets up to 900mm, envelope printing with the standard fuser and amazing quality on textured media, it’s so simple one operator can run even the most complex projects. So now you can say yes to more opportunities that will grow your business.
  • EXCEPTIONAL DURABILITY - Reliability drives profitability. So new technologies built into the engine include a more durable lubricated drum, double corona wires with automatic cleaning, an optimized paper transport solution and a double swing registration system for improved paper compatibility and feeding accuracy.

Specifications & Downloads

Specifications & Downloads

READY-MADE PRINT PRODUCTS
  • 50-sheet booklet making with front trimming and optional creasing, slitting and spine corner forming
  • Perfect binding for books of up to 30 mm
  • 100-sheet stapling with cutting mechanism
  • 102-sheet auto ring binding
  • Automated inline business card and postcard cutting
  • Full bleed banners, A3 and A4 posters
DURABLE PERFORMANCE
  • Duty Cycle of up to 1.62 million prints
  • Up to 90 A4 colour pages per minute
  • Up to 48 SRA3 colour pages per minute
GEARED-UP FINISHING
  • Multi (GBC) punching and 2- & 4-hole punching
  • 6 different types of folding
  • 3rd–party Products
  • Large-capacity stacking
  • 2 Perforations in feed direction, 5 Perforations in Cross feed direction
  • Up to 5 Creases downwards or upwards
SIMPLY EFFICIENT
  • Automated engine linearisation
  • Automated duplex registration
  • Automated profiling
  • Real-time adjustments
  • Purge function
HIGHEST RELIABILITY
  • Long-life platform, long-lasting parts and consumables
  • Accurate front to back registration
  • For prints with maximum efficiency
  • For lucrative short-run printing
HIGH-END PRINT CONTROL
  • Flexible choice of controller technology: EFI®, CREO® or proprietary Konica Minolta controller
  • Integration into hybrid workflows
EASE OF USE
  • Simple paper catalogue settings
  • Operator Replaceable Parts
  • Auto Inspection Technology
PERFECT IMAGE QUALITY
  • S.E.A.D. X 2,400 x 3,600 equiv. dpi x 8bit
  • Simitri V toner technology
  • Image density control technology
SOPHISTICATED MEDIA HANDLING
  • Automatic media recognition
  • Air-suction feeding technology
  • Up to 15,150 sheets paper input capacity
  • Up to 11 paper input trays
  • Up to 2,300 sheets paper input for long sheets (up to 900 mm)
COMPREHENSIVE MEDIA PROCESSING
  • Up to 400 g/m2 paper weight in simplex and duplex printing
  • Long sheet size of up to 1,300 mm (duplex up to 900 mm )
  • Reliable thin paper feeding through air-blow fusing separation
  • Envelope printing
  • Embossed paper support
  • Optional inter-cooler curl eliminator

SYSTEM SPECIFICATIONS

Resolution 2,400 x 3,600 equiv. dpi x 8 bit
Paper Weight 52–400 g/m²
Duplex Unit Non-stack type; 52–400 g/m²
Paper sizes 330.2 x 487.7 mm
330.2 x 900 mm (max.duplex)
330.2 x 1,300 mm (max. simplex)
Paper input capacity 15,140 sheets
Main unit dimensions (W x D x H) 800 x 1,138 x 1,478 mm
Main unit weight 335 kg

PRODUCTIVITY
A4 colour - max. per minute 90 ppm
A4 mono - max. per minute 110 ppm
SRA3 colour - max. per minute 48 ppm
SRA3 mono - max. per minute 58 ppm
A4 colour - max. per hour 5,047 pph
A4 mono - max. per hour 6,103 pph

  • All specifications refer to A4-size paper of 80 g/m2 quality.
  • The support and availability of the listed specifications and functionalities varies depending on operating systems, applications and network protocols as well as network and system configurations.
  • The stated life expectancy of each consumable is based on specific operating conditions such as page coverage for a particular page size (5% coverage of A4). The actual life of each consumable will vary depending on use and other printing variables including page coverage, page size, media type, continuous or intermittent printing, ambient temperature and humidity.
  • Some of the product illustrations contain optional accessories.
  • Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
  • Konica Minolta does not warrant that any prices or specifications mentioned will be error-free.
  • All brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.
